รายละเอียดสินค้า:
การชำระเงิน:
|
| PoE Standard: | IEEE802.3af (15.4W) | Data Rate: | 10/100/1000M |
|---|---|---|---|
| Fiber Type: | Multi-mode | Distance: | 550m |
| Connector: | RJ45 / SC | Power supply: | AC 100-240V |
| เน้น: | single mode fiber media converter,poe powered media converter |
||
Overview
LNK-POE1000 series is a 10/100/1000Base-TX to 1000Base-FX (also can be forced to 100Base-FX) media converter, which allows two types of network segment to be connected easily. Complied with IEEE802.3at or IEEE802.3af standard, the AC/DC powered PoE media converter is a Power Sourcing Equipment (PSE) which combines data transfered over a fiber optic link with 48V (or other voltage) power supply, providing power to IEEE802.3at or IEEE802.3af powered device (PD) over CAT5e/CAT6 UTP cable (cable length up to 100meters / 330feets). The converter includes a single port PSE controller, which offers PD signature sensing and power monitoring features. Other features include over-current protection, LFP function, etc. The LFP (Link Fault Pass-through) allows the media converter to monitor both the fiber and copper RX port for loss of signal. In case of a loss of RX signal on one media port, the converter will automatically disable the TX signal to the other media port, thus passing through the link fault.
Features
Technical Indexes
| Data Rates | 10/100/1000Mbps(IEEE802.3U IEEE802.3z 1000Base-Tx) |
| 1000Mbps (1000Base-FX) or 100Mbps (100Base-FX) | |
| Input Power Requirements | |
| Input voltage | 100 VAC to 240 VAC |
| Input frequency | 47 Hz to 63 Hz |
| Power over Ethernet Output | |
| Pin Assignment and Polarity | |
| For IEEE802.3af standard | 1/2 (V+),3/6 (V-) |
| For IEEE802.3at standard (30watts maximum) | 1/2 (V+),3/6 (V-) |
| For IEEE802.3at standard (50watts maximum) | 1/2/4/5 (V+),3/6/7/8 (V-) |
| Output Power | please refer to ordering information |
| Efficiency | 75% min |
| Short circuit protection | auto recovery |
| Over current protection | auto recovery |
| Environmental Conditions | |
| Operating temperature | 0℃ to 50℃ |
| Cooling | free air convection |
| Storage temperature | -20℃ to +85℃ |
| Operating Humidity | 90% max, non-condensing |
| Mechanical Specifications | |
| Case Material | Iron |
| Case Color | Black |
| Net Weight | 560g approx. / unit |
| Dimensions | 110(W) x 40(H) x 140(L) (mm) |
| Do not include transceiver length | |
| Connectors | |
| AC Inlet | IEC-J-4 |
| LAN | Shielded RJ-45 |
| Fiber | see ordering information |
Application
